Red Roo 1290 230mm (9")

BEST IN CLASS
Available

Red Roo 1290 Commercial Wood Chipper is a ideal for an arborist, lawn and garden contractor, golf course, large acreage owner, or rental company. The 1290 is powered by either a 40hp (30kw) Briggs and Stratton Vanguard EFI or a 54HP (40kw) Kubota Petrol engine. The Red Roo 1290 uses an exclusive sliding carriage to engage the chipper disk on the Vanguard Powered option and and a heavy duty over centre clutch on Kubota powered option. A massive 300mm (12") x 230mm (9") feed opening allows for quick processing of branches with a diameter up to 230mm (9"). This unit is also incorporated with a lift and crush feature that allows more effecient processing of small branches and bushy type material.



40HP EFI BRIGGS & STRATTON

The unrelenting 40HP BIG BLOCK™ engines feature EFI and ETC technology — reducing fuel consumption and maintaining power when your application demands it





Consummate Balance of Capability and Power

Achieve high productivity with the Red Roo 1290 Wood Chipper which now features a 37HP Engine with Electronic Fuel Injection (EFI). The machine provides the perfect balance of capability and power for crews doing a variety of trimming operations. The 1290 features high-end design elements like concealed wiring, integrated manifold hydraulics with electronic control and sliding engine disk engagement.

Bushfire Preparation

The video demonstrates the capabilities of the Red Roo 1290 Wood Chipper as a tool for preparing for bushfires by clearing vegetation. If you live in a rural area you may not need a permit to clear trees from around your home. Reducing the vegetation around your home is one of the most important things you can do to keep your property safe in a bushfire. Depending on where you live, the 10/30 rule and the 10/50 rule might apply. Check with your local council.

Bushfire Preventation Cutting Trees Back

The Red Roo 1290 Wood Chipper can be an essential tool in assisting property owners to prevent the extent of damage from bushfires. The video illustrates the 1290 being used in an application to clear an area after a tree has been cut down. Clearing up your property prior to the bushfire season has never been an easy task. The 1290 is just the product to assist you in preparing for the bushfire season.



Hire Wood Chipper in Ballarat and Western District

Red Roo provides an unqualified recommendation for customers wishing to hire a Red Roo 1290 Wood Chipper from Bylsma Hire located in Ballarat. Red Roo and Bylsma Hire have a relationship which extends over 35 years and has seen Bylsma Hire become one of our most important Hire and Rental partners. We encourage you to visit their website at Bylsma Hire for a more comprehensive perspective of their capabilities and hire and rental products.

Stones in Chipper

These images below demonstrate the incorrect use of the 1290 whereby a customer completely ruined the chipper blades by feeding material contaminated with stones. This practise must be avoided at all costs.

1290 Stones































Red Roo 1290 230mm 9
Red Roo 1290 230mm 9
Red Roo 1290 230mm 9
Red Roo 1290 230mm 9
Red Roo 1290 230mm 9andquot
Red Roo 1290 230mm 9andquot
Red Roo 1290 230mm 9
Red Roo 1290 230mm (9")
Red Roo 1290 230mm 9andquot
Red Roo 1290 230mm 9andquot
Red Roo 1290 230mm 9andquot
Red Roo 1290 230mm 9
Red Roo 1290 230mm 9
Red Roo 1290 230mm 9
Red Roo 1290 230mm (9")
Red Roo 1290 230mm 9
Red Roo 1290 230mm (9")
Red Roo 1290 230mm (9")
Red Roo 1290 230mm (9")
Red Roo 1290 230mm (9")
Spread the word
  • Specifications
  • Features
  • Photos
  • Manuals
  • Videos
  • Reviews
Engine
40hp(30kw) Briggs and Stratton Vanguard V-Twin EFI
54hp(40kw) Kubota Petrol WG1605G
85.5mm (Briggs Only)
86.5mm (Briggs Only)
993cc (Briggs Only)
3600 RPM (Briggs Only)
53 Ft Lbs (Briggs Only)
Forced Air (Briggs Only)
Two Stage Dry Type
Full Flow Spin On
946 Millilitre (2.3 Quarts) (Briggs Only)
10W-30
12v
Sliding Positive Lock Engagement
General
3.35m (132")
2.36m (93")
1.7m (67")
1329kg (2930lbs) Briggs / 1640kgs (3608lbs) Kubota
205/75R14 Ld Rng C 1760 # @ 50 PSI
Dexter Torflex 2358kg Cap
34ltr (9 gallons)
Two stage dry type
305mm x 230mm (12" x 9")
29HVD 650 CCA
2000 # Cap Screw Type Swing Up
Hydraulics
Direct drive off engine mount
34ltr (9 gallons)
2500 PSI
.329 in cu/rev
5.33 GPM
AW32
Series Type
16,000 PSI Burst - Exceeds SAE 100R2
10 Micron Return with Suction Strainer
Bearings
6.2cm (2 .4") Tapered roller
5cm (2") Tapered roller
8.9cm (3.5") Removable
5cm (2") Engagement
2.5cm(1" )Flanged Ball
Chipper Disk
760mm (30")
38mm (1.5")
1440 RPM Nominal
2
258mm x 101mm x 12mm (10.19" x 4" x0.5")
Precision High Speed Balanced
100mm (4") x 22mm (8.8")x 13mm (0.5")
Two 9mm (.375") x 100mm (4") x 280mm (11")
Feed System
Digital fully adjustable
31m (100`) per minute
360 adjustable swivel with deflector
5.41 GPM
Live- Driven off engine
26cm(10.25") x 29cm (11.5")
Two 38cm(15") Tight Wound Powder Coated
Two2.5cm (1") Flange Mount
5cm(2") x 25cm(10") with 2.5cm(1") attachment
Top-32.7 in cu
Construction
50 x 100mm with 6mm wall (2" x 4" with 1/4" wall)
10ga with 25mm (1") tube frame
10 gauge checker plate aluminium
12mm (1/2") plate
5mm (3/16") with hidden wiring
Sliding Positive Lock Engagement
C4 x 5.4 Channel
10ga with 25mm (1") tube frame
5mm (3/16") thk
10 gauge neck with 14 gauge discharge
19mm (3/4") Spring Loaded Pin
10 gauge with baffles rubber mtd
10 gauge with baffles rubber mtd
Marine Battery Box
38mm(1 1/2") OD x 3.2mm(1/8") wall - removable
19mm(3/4") Plate adjustable 203mm(8") Up/Down
Drive System
6/3V5.6
6/3V14.0
6 Band 6/3V750
Features
Digitally Controlled Autofeed
300mm x 230mm (12" x 9") Feed Opening
Folding Feed Table
Extra large diameter feed roller
High-torque Dual Feed Motors
Precision Ground High Speed Balanced Chipping Disk
Kevlar Construction Drive Belts
LED Taillights & Side Marker Lights
Heavy Duty 38mm(1/1/2") Feeder Bar
Heavy Duty 907kg (2000lb) capacity tongue rack
Swivel Discharge
Locking Fuel and Hydraulic Tanks
122cm(48") Wide Feed chute
Warranty
Machine Warranty: 12 months against defective materials, design, and workmanship
Engine Warranty: As per manufacturers specifications
Manuals: Operator instructions, hazard assessment, maintenance, & spare parts manuals supplied with each machine
